Furutech DAS-4.1 XLR Interconnect Cable Pair DIY Kit

Description

Made with Furutech DAS 4.1 OCC/DUCC Balanced Audio Cable, our Furutech DAS-4.1 XLR Interconnect Cable Pair DIY Kit is made for audiophiles seeking the highest quality system connections, and want to make do it yourself high end Balanced XLR interconnect cables,
BASE PRICE IS FOR A DIY PAIR of 3 ft. CABLES with Furutech CF-601 M NCF and Furutech CF-602 F NCF Rhodium Plated XLR connectors.  Please choose the length cable you need, and the prices will adjust accordingly.

Click here to see a Furutech video of our master cable builder showing you how to make your Furutech DAS-4.1 Interconnect Cable (XLR) using Furutech top-of-the-line CF-601M NCF / CF-602F NCF XLR

The Furutech DAS-4.1 XLR Interconnect Cable Pair DIY Kit is designed with the High End Audio enthusiasts in mind who likes to DIY their own cables. These cables incorporate Furutech DAS-4.1 OCC/DUCC Balanced Audio Cable, and Furutech CF-601 M NCF and CF-602 F NCF Rhodium Plated high performance XLR connectors.  Both the cable and the connectors are treated with the α(Alpha) process. Furutech’s α(Alpha) process consists of  Two-Stage Cryogenic and Demagnetization treatment.  ALL metallic parts used in Furutech products go through the Alpha Process treatment to keep all connectors, conductors, and metal parts in a perfect stress-free, stable and highly conductive state.

Furutech’s α (Alpha) OCC‐DUCC is one of a select few of conductors that Furutech engineers have found to excel in sound reproduction. α (Alpha) OCC –DUCC is constructed using a combination of DUCC Ultra Crystallized High Purity Copper and Furutech’s world famous Pure Transmission α (Alpha)-OCC.

Furutech DAS-4.1 RCA Interconnect Cable Pair DIY Kit SPECIFICATIONS
Conductor Material Alpha-OCC + α-DUCC (7N Class)
Construction (pcs／mm）
Inner – 59 / 0.13 α-OCC (Right rotate)
Middle – 29 / 0.13 α-DUCC (Left rotate)
Outer – 36 / 0.13 α-DUCC (Right rotate)
Diameter （mm）1.67 Approx.
Size 15AWG / 1.65 Sq.mm

Insulation Material
Audio Grade PP (Polypropylene, Red for”+”、White for “-“)
Mom. Thickness （mm）0.47 Approx.
Diameter （mm）2.6 Approx.
Twisting Method
2 Cores Twisted Together
Fillers Polyester yarn
Barrier Layer
Non-Woven Fabric wrap
Shield Method
Cu-Foil wrap + Braided (24×6 / 0.13 α- OCC) + Paper wrap
Inner Sheath
Material Audio Grade Flexible PVC (Black)
Nano-Ceramic / Carbon particle compound
Diameter （mm）7.8 Approx.
Outer Sheath
Material
Audio Grade Flexible PVC (Dark purple)
Nom. Thickness（mm）0.7 Approx.
Diameter （mm）9.2 Approx.
Outer Sleeve
Material
PP yarn stranded braid(Black/Blue)
Overall Diameter （mm）
10.0 Approx

Furutech CF-601 M NCF Features:
• Rhodium-plated α (Alpha) Pure copper one-piece construction conductor pin injected with heat resistant NCF Liquid Crystal Polymer Resin.
• Nylon, fiberglass, nano-sized crystalline piezo ceramic particles, carbon powder and Furutech special “NCF” anti-resonance damping material main body combine heat resistant NCF Liquid Crystal Polymer Resin. NCF delivers improvements in the depth and focus of the sound stage, harmonics and tonal balance. Low frequencies are cleaner, with a greater sense of definition made possible by a lowered noise floor.
• Housing: Multilayer hybrid NCF carbon housing composed of an outer hard clear coat over with another layer of Hybrid NCF Silver plated 3k carbon fiber on a nonmagnetic stainless-steel Housing. The best of damping and insulation materials improve frequency extension and tonal balance.
• Conductor wire fixed by set screw or soldering.
• Specified for cable diameters max. 10.0mm.
• Accommodates: 14AWG (2.08 sq.mm) max. stranded wire / 12AWG (3.3 sq.mm) max solid core wire. Wire diameter 2.1mm max.
Multi-material Housing, Pin and Body structure description
Aluminum color ring
Nylon, fiberglass, nano-sized crystalline piezo ceramic particles, carbon powder and Furutech special “NCF” anti-resonance damping material main body.
Housing: Multilayer hybrid NCF carbon housing composed of an outer hard clear coat over with another layer of Hybrid NCF Silver plated 3k carbon fiber on a nonmagnetic stainless-steel Housing
Outer layer – Special hardened clear coating
Hybrid NCF silver plated 3k carbon fiber
Nonmagnetic stainless-steel housing
Specially designed set screw or solder contact points

Furutech CF-601 M NCF Specifications:
Dimensions: ø18.6mm X 64.6mm overall length approx.
Net Weight: 46.9g approx.
Nonmagnetic stainless-steel hexagon socket set screws
Conductor wire fixed by set screw or soldering
Pin centers are injected with heat resistant NCF Liquid Crystal Polymer Resin
Rhodium-plated α (Alpha) Pure copper one-piece construction conductor pin injected with heat resistant NCF Liquid Crystal Polymer Resin.
Heat resistant NCF Liquid Crystal Polymer Resin
Rhodium-plated α (Alpha) Pure copper one-piece construction conductor pin

Furutech CF-602 F NCF Female High End Performance XLR Connector  Features:
• Rhodium-plated α (Alpha) Pure copper one-piece construction conductors.
• Nylon, fiberglass, nano-sized crystalline piezo ceramic particles, carbon powder and Furutech special “NCF” anti-resonance damping material main body combine heat resistant NCF Liquid Crystal Polymer Resin. NCF delivers improvements in the depth and focus of the sound stage, harmonics and tonal balance. Low frequencies are cleaner, with a greater sense of definition made possible by a lowered noise floor.
• Special resonance damping composite release button – formed with stainless steel powder and vibration resistant metal powder.
• Chrome-plated brass stamped housing.
• NCF material damping clips
• Housing: Multilayer hybrid NCF carbon housing composed of an outer hard clear coat over with another layer of Hybrid NCF Silver plated 3k carbon fiber on a nonmagnetic stainless-steel Housing. The best of damping and insulation materials improve frequency extension and tonal balance.
• Conductor wire fixed by set screw or soldering.
• Specified for cable diameters max. 10.0mm.
• Accommodates: 13AWG (2.62 sq.mm) max. stranded wire / 12AWG (3.3 sq.mm) max solid core wire. Wire diameter 2.4mm max.
SPECIFICATIONS

Furutech CF-602 F NCF Female High End Performance XLR Connector Specifications:
Dimensions: ø18.6mm X 70.85mm overall length approx.
Net Weight: 58.2g approx.

Accessories
2mm hex head screwdriver (H2.0)*1 PC
1.27mm*50L hex head screwdriver(H1.27)*1 PC
